Raycus Power source

Raycus Laser source 1.5kw-12kw

₹245,000.00

RFL-CE CERTIFIED 1500W-20000W
Raycus Power Source – Key Features:

  • Model – RFL-CE CERTIFIED
  • Warranty: Comes with a standard 2-year manufacturer warranty for peace of mind.
  • High Performance: Delivers stable and efficient fiber laser output for precise applications.
  • Energy Efficient: Low power consumption with maximum output efficiency.
  • Durable Design: Built for long service life and consistent performance.
Category:

🔹 Raycus Fiber Laser Power Source – Overview

Raycus is a leading manufacturer of fiber laser sources based in China, known for its reliable, high-efficiency laser modules used in industrial applications. Their product line ranges from low-power (20W) to ultra-high-power (100kW+) systems, offering CW (Continuous Wave) and pulsed options.

⚙️ Key Features

  • High Electro-Optical Conversion Efficiency: Up to 40–50%

  • Stable Output Power: Fluctuation <1%

  • Long Service Life: Designed for >100,000 hours

  • Excellent Beam Quality: M² < 1.3 (for single-mode lasers)

  • Low Maintenance: Air-cooled or water-cooled depending on model

  • Flexible Control Interfaces: RS232, Ethernet, Analog, Digital I/O

📋 Common Models & Specifications

🔸 Raycus CW Fiber Lasers (for Cutting & Welding)

Model Power Output Wavelength Cooling Beam Quality Modulation Frequency Application
RFL-1000S 1000 W 1070 ±10 nm Air/Water <1.3 0–50 kHz Cutting/Welding
RFL-1500S 1500 W 1070 ±10 nm Water <1.3 0–50 kHz Welding/Cutting
RFL-3000S 3000 W 1070 ±10 nm Water <1.3 0–5 kHz Cutting 10–20mm
RFL-6000S 6000 W 1070 ±10 nm Water <1.3 0–5 kHz Heavy Cutting
RFL-12000S 12,000 W 1070 ±10 nm Water <1.5 0–5 kHz Industrial Use

🔸 Raycus Pulsed Fiber Lasers (for Marking & Cleaning)

Model Output Power Pulse Energy Pulse Width Frequency Range Application
RFL-20W 20 W 0.8 mJ 80–120 ns 20–80 kHz Metal Marking
RFL-50W 50 W 1.25 mJ 90–130 ns 20–100 kHz Deep Engraving
RFL-100W 100 W 1.5 mJ 80–130 ns 30–200 kHz Rust Removal
RFL-200W 200 W 2 mJ 90–130 ns 40–250 kHz Surface Cleaning

🔌 Electrical & Physical Specs (Typical)

  • Input Voltage: 220V or 380V (depending on model)

  • Frequency: 50/60Hz

  • Control Interface: DB25, RJ45, RS-232/485

  • Cooling Type: Air-cooled (≤1kW) / Water-cooled (≥1.5kW)

  • Dimensions (1000W): ~448×360×130 mm

  • Weight (1000W): ~25–30 kg

✅ Applications

  • Laser Cutting: MS, SS, Al, Brass, Copper

  • Laser Welding: Auto parts, battery, mold repair

  • Laser Marking/Engraving: Tools, electronics, nameplates

  • Laser Cleaning: Paint, rust, oxide layer removal

📦 What Comes with Raycus Laser Source

  • Main laser source unit

  • Power and signal cables

  • Communication interface

  • Optional: Cooling unit (if required)

  • Operation & safety manual

🛡️ Warranty & Support

  • Warranty: 1 YEAR INDIAN  (standard for most models)

  • MTBF: >100,000 hours

  • Support: Global technical service & spare parts availability
